Threaded Anchor Rods

Price 12734.00 INR/ Piece

Get a Price/Quote

Threaded Anchor Rods Specification

Size
Customized

Length
Customized Inch (in)

Product Type
Threaded Rods For Chemical Anchoring

Material
carbon Steel

Type
Concrete Anchor

Diameter
8 to 39 Millimeter (mm)

Surface
Polished

Grade
5.8 / 8.8 / 10.9 / SS304 / SS316

Threaded Anchor Rods Trade Information

Minimum Order Quantity
50 Pieces

Payment Terms
Cash on Delivery (COD), Cash Against Delivery (CAD), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Pieces Per Day

Delivery Time
7 Days

Main Domestic Market
South India

About Threaded Anchor Rods

DESCRIPTION:

Threaded Anchor Rods are generally used in combination of Chemical Anchoring System either by Injected System or Chemical Capsule Anchors. Threaded Rods are also known in the industry as Anchor Rods, Stud Anchors and Threaded Anchor Rods. KTR is an acronym of KWIK Threaded Rod Threaded Anchor Rods are generally fully threaded along their complete length for use with Injection System of Chemical Anchors. The Threaded Rods used in conjunction with Chemical Anchoring System are subjected to Tensile, Shear, Bending Moments or Combination Loads. Also these anchors are generally subjected to a very high static and live Loads hence the Grade of the Steel plays a vital role in usage. Various grades of steel like 4.6, 5.8, 8.8, 10.9 and B7 which are manufactured with the Carbon Steel material whose mechanical properties meet or exceed the requirements set forth in the relevant harmonized standards.

Consistent Pitch Diameter :Uniform thread pitch
Grades Available:5.8Gr., 8.8Gr., 10.9Gr., B7Gr. SS304-A2 & SS316-A4
Lengths Available: 8mm to 64mm dia, & 100mm to 3000mm lengths

Size Available

KTR - Anchor Threaded Rods (Steel Grade - 5.8, 8.8, 10.9, SS304-A2 & SS316-A4)

ZINC GALVANIZED STEEL WITH NUT & WASHER

PRODUCT DESCRIPTION	ANCHOR DIA.	FASTENABLE THICKNESS - t_fix	EMBEDMENT DEPTH - h_ef	TOTAL LENGTH	BOX QTY.
PRODUCT DESCRIPTION	(mm)	(mm)	(mm)	(mm)	BOX QTY.
KTR M8 x 85	M8	5	60	85	50
KTR M8 x 110	M8	10	80	110	50
KTR M8 x 150	M8	50	80	150	50
KTR M10 x 90	M10	5	75	90	50
KTR M10 x 115	M10	5	90	115	50
KTR M10 x 150	M10	40	90	150	50
KTR M10 x 200	M10	90	90	200	25
KTR M12 x 120	M12	10	90	120	25
KTR M12 x 150	M12	20	110	150	25
KTR M12 x 200	M12	70	110	200	25
KTR M12 x 250	M12	120	110	250	10
KTR M12 x 300	M12	170	110	300	10
KTR M12 x 400	M12	270	110	400	10
KTR M16 x 150	M16	5	125	150	10
KTR M16 x 170	M16	20	125	170	10
KTR M16 x 200	M16	50	125	200	10
KTR M16 x 250	M16	100	125	250	10
KTR M16 x 300	M16	150	125	300	10
KTR M16 x 350	M16	200	125	350	10
KTR M16 x 500	M16	350	125	500	5
KTR M20 x 150	M20	10	110	150	5
KTR M20 x 200	M20	45	125	200	5
KTR M20 x 250	M20	50	170	250	5
KTR M20 x 300	M20	100	170	300	5
KTR M20 x 350	M20	150	170	350	5
KTR M20 x 500	M20	300	170	500	5
KTR M22 x 200	M22	20	150	200	5
KTR M22 x 300	M22	90	180	300	5
KTR M22 x 400	M22	190	180	400	5
KTR M24 x 200	M24	10	150	200	5
KTR M24 x 250	M24	60	150	250	5
KTR M24 x 300	M24	50	210	300	5
KTR M24 x 350	M24	100	210	350	5
KTR M24 x 450	M24	200	210	450	5
KTR M27 x 300	M27	20	240	300	5
KTR M27 x 400	M27	120	240	400	5
KTR M27 x 500	M27	220	240	500	5
KTR M30 x 350	M30	35	270	350	5
KTR M30 x 500	M30	185	270	500	5
KTR M33 x 400	M33	40	300	400	5
KTR M33 x 550	M33	190	300	550	5
KTR M36 x 550	M36	160	330	550	5
KTR M39 x 550	M39	130	360	550	5
KTR M39 x 1000	M39	580	360	1000	3
